Kalibrieren des Color Reference System
Vorbereiten des Systems für die Kalibrierung 1 2 3 4 5 1 2 Vergewissern Sie sich, dass die Farben auf "Millionen" oder mindestens 16-Bit-Farbe eingestellt sind. Der Bildschirm muss sich im Modus "Professional" befinden. Drücken Sie dazu die Taste "Picture Effect" an der Vorderseite des Bildschirms GDM-C520, bis auf dem Bildschirm die Anzeige "Professional" erscheint. Lassen Sie den Bildschirm vor dem Kalibrieren mit recht hellem Bildschirm (über 50 % wei�) eingeschaltet, damit er sich erwärmen kann. Vergewissern Sie sich, dass der Color Reference-Sensor an einen der USB-Anschlüsse des Computers angeschlossen ist. Verringern Sie die Beleuchtung im Raum auf unter 64 lx. Idealerweise sollte die Umgebungsbeleuchtung etwa 16 lx betragen. Doppelklicken Sie auf das Color Reference-Symbol, um die Anwendung zu starten. Der Hauptbildschirm wird angezeigt. Wählen Sie einen Zielfarbraum aus dem Dropdown-Menü "Target Colorspace". Wählen Sie eine der drei folgenden Optionen aus: Print RGB D50: Standardfarbraum für professionelle Druckvorstufe und Druck in den USA. Print RGB D65: Standardfarbraum für professionelle Druckvorstufe und Druck in Europa. Web RGB (sRGB): Standardfarbraum für Ausgabe über Computerbildschirme, Fernsehgeräte und Videos. 3 4 5 6 7 Klicken Sie auf die Schaltfläche "Calibrate". Zentrieren Sie den Color Reference-Sensor über dem Ziel in der Mitte des Bildschirms und verwenden Sie dazu die Kontrollmarkierungen auf dem Bildschirm und dem Sensor. Klicken Sie auf die Schaltfläche "Start". Es dauert etwa 10 Minuten, bis das System vollständig kalibriert ist. Wenn die Kalibrierung abgeschlossen ist, erscheint die Meldung "Calibration Complete". Entfernen Sie den Color Reference-Sensor. Die neue Kalibrierung ist nun aktiv und wird unter dem Dropdown-Menü "Calibration Data" auf dem Hauptbildschirm angezeigt.
Kalibrieren des Systems
Technische Daten - Kurzübersicht
Betriebsspannung Betriebstemperatur Abmessungen Gewicht (nur Bildschirm) In der Verpackung enthaltenes Zubehör 100 � 240V ~ 50 � 60Hz, 2,0 � 1,0 10°C � 35°C ca. 497 x 499 x 487 mm ca. 30,5 kg Bildschirm GDM-C520 Netzkabel Color Reference-Signalkabel Color Reference-Sensor und Schutzhülle Bildschirmhaube Fixierlaschen (für die Bildschirmhaube) Color Reference System-CD Kurzreferenz Garantiekarte
Wenn Sie weitere Informationen zum Konfigurieren des Bildschirms oder Kalibrieren des Systems benötigen, schlagen Sie bitte im Benutzerhandbuch auf der Artisan Color Reference System-CD nach. Wenn Sie darüber hinaus Unterstützung brauchen, wenden Sie sich an Sony unter http://www.sony.com/displays/support oder telefonisch unter 1-866-256-9392.
6
|
|
|
> |
|
