CHAPTER 8 PAPER DECK
7. Routing the Lifter Cable 1) Check to make sure that the lifter drive shaft and the lifter are held in position by a hex wrench [1] and screwdrivers [2], respectively. 2) Secure the lifter fixing plate [3] in place to the lifter with two screws. 3) Hook the lifter cable on the pulley [4]. 4) Hook the ball of the lifter cable on the pulley [5] of the lifter drive shaft; then, wind it along the pulley groove about 1.5 times. (At this time, be sure to keep the lifter cable taut so that the long screwdrivers are slightly pulled up.) 5) Secure the pulley in place to the lifter drive shaft with two set screws [6]. 6) Secure all pulleys to the lifter drive shaft; then, measure the distance between the bottom plate of the compartment to the top face of the lifer to make sure that the lifter is level.
[4]
[3] [4]
(rear) [5] [6] [3]
[3] [6] [5] [1] [3] Figure 8-337 [2]
COPYRIGHT © 1999 CANON INC. CANON 405/335 REV.0 JAN. 1999 PRINTED IN JAPAN (IMPRIME AU JAPON)
8-35
|
|
|
> |
|
|
