SETTINGS
____________________________________________________________________________
Adjusting the TV set to the video recorder
This adjustment is not necessary if the video recorder and the TV set are connected with a EURO-AV cable.
Preparation
Switch the TV set on. On the TV set, select the »AV« programme position for video playback via the aerial socket. Consult also the user manual of your TV set.
Adjustment
1 Switch the video recorder on using the » D « button. 2 Press the » DUB « button for about 3 seconds.
� »2 1 R F «, for example, is displayed on the video recorder (21 is the output channel of the video recorder). The video recorder now emits a test pattern.
3 Search the test pattern on the TV set in the UHF range on a channel between
21 and 69 (channel 21 in the example).
4 Store the setting on the TV set. 5 Press the » DUB« button to end the setting.
Improving the picture quality
If the quality of the �recorder picture� is poor, or the picture quality of one or more TV programmes on the TV set gets worse, you must search a different �free� channel on the TV set.
1 Switch the video recorder on using the » D « button. 2 Press the » DUB « button for about 3 seconds.
� »2 1 R F «, for example, is displayed on the video recorder (21 is the output channel of the video recorder). The video recorder now emits a test pattern.
3 On the TV set in the UHF range between channel 21 and channel 69, search
for a �free� channel on which no TV programme is received (only snow and sound noise).
4 Use the » * � « buttons on the video recorder to change the output channel
of the video recorder until the test pattern appears on the picture screen of the TV set. Press the »OK« button to store the setting.
5 Store the channel on the TV set. 6 Press the » DUB« button to end the setting.
11
ENGLISH
|
|
|
> |
|
|
