I was having a hard time finding the problem with this Mackie 1604 unit. I didn't have a schematic. Went looking on the web and found your site and the price was more then reasonable. Ordered it and within the hour had the manual and within 15 minutes had the unit fixed. Best $4.99 I ever spent. Thank you.
Doug
;
This is a service manual in every sense of the word ( French and German versions of the text are included, as well as English..)
There are explanations of the mechanical and electrical functions, plenty of mechanical drawings, and the needed schematics. The quality of the scanning is excellent - all the component values are clearly legible - and very usefully there are pcb component layouts, so you can find a component on the schematic, and then very quicky pinpoint its physical location on the relevant pcb.
I cannot see how I can give this manual any less than the maximum 5 stars! Great value for money, which will pay for itself immediately. Excellent all round!
;
the manual is great and especially hard to find... thanks for the great service and having a hard to find manuel_
;
Please tell us what you think and share your opinions with others. Be sure to focus your comments on the product. You will receive $2.50 of store credit for Your review.
;
hat alles sehr gut geklappt. Das Servicemaual ist gut zu verwenden. Die Pläne und Schrift
ist klar und leserlich. Außerdem preiswert. Grüße an alle Hifi-Bastler
5-5. CTL/TC Head Height Adjustment
Adjustment 7. In Case the Level Increases when the Tape is Pressed Down (Fig. 1) Turn the height adjustment screw clockwise and adjust so that the output waveform is maximum. 8. In Case the Level Increases when the Tape is Pushed Up (Fig. 2) Turn the height adjustment screw counterclockwise and adjust so that the output waveform is maximum. In case the adjustment is performed 9. Adjust the CTL/TC Head Azimuth Refer to Section 5-6.
Height adjustment screw
<Fig. 1>
10. Adjust the CTL/TC Head Position Refer to Section 5-7. 11. Check the CTL/TC Head Height Refer to steps 6 and 7 in this section. 12. Check the CTL/TC Head Azimuth Refer to Section 5-6.
maximize
<Fig. 2>
Height adjustment screw
maximize
CTL/TC Head Height Adjustment
5-24
GY-2120WD/WS
|
|
|
> |
|
