3. SISTEMA MECCANICO
B. Gruppo della guida di trasporto
1) Rimuovere il pannello anteriore. 2) Togliere la vite w e togliere il supporto della leva di comando del blocco di aggancio q.
w
q
Figura 3-102 3) Togliere la leva di comando del blocco di di aggancio e ed il blocco di aggancio r. 4) Togliere le viti t e rimuovere il gruppo della guida di trasporto y.
e
y
r
t
Figura 3-103
3�2
Manuale Tecnico Stapler Sorter-H1 Rev. 0 Ed. Italiana
Canon Italia S.p.A.
|
|
|
> |
|
