- SERVICING NOTES
- GENERAL
- Location of Controls
- Setting the Time
- DISASSEMBLY
- TEST MODE
- MECHANICAL ADJUSTMENTS
- ELECTRICAL ADJUSTMENTS
- DIAGRAMS
- Block Diagram - CD Section
- Block Diagram - TAPE DECK Section
- Block Diagram - MAIN Section
- Block Diagram - DISPLAY/POWER SUPPLY Section
- Note for Printed Wiring Boards and Schematic Diagrams
- Printed Wiring Board - CD Section
- Schematic Diagram - CD Section
- Printed Wiring Boards - TAPE DECK Section
- Schematic Diagram - TAPE DECK Section
- Printed Wiring Board - MAIN Board
- Printed Wiring Boards - LCD/LOADING Boards
- Schematic Diagram - MAIN Section (1/3)
- Schematic Diagram - MAIN Section (2/3)
- Schematic Diagram - MAIN Section (3/3)
- Printed Wiring Boards - AMP/HEADPHONE Boards
- Schematic Diagram - POWER AMP Section
- Printed Wiring Board - CONTROL Board
- Schematic Diagram - KEY CONTROL Section
- Printed Wiring Board - POWER Board
- Schematic Diagram - POWER SUPPLY Section
- IC Pin Function Description
- EXPLODED VIEWS
- ELECTRICAL PARTS LIST
There are currently no product reviews.
 ;
The item received was as described, as expected. I was pleased with the order. Thank you.
 ;
Superb rendition. Drawings (schematics) complete and unabridged. I do a great deal of vintage audio restoration. Documentation is essential for successful repairs. I have found sources over the years that offer good documentation, but rarely all that is necessary. Owner's Manuals has filled that void with complete and legible documentation. They have narrowed my "favorites" to a more manageable collection. This Denon manual in particular contained the latest revisions level, and offered alterations favorable to updating the item. The Illustrated Parts Breakdown (IPB) was well enough detailed to simplify part symbols and physical locations. You will not be disappointed!
;
Clear and concise. Saved me a lot of time and money.
;
Superb manual. Exactly what I ordered and made available in a very timely manner.
;
very fast detailed and accurate hope to do business again
� SUB CHASSIS (2130) INSTALLATION
Note: Follow the assembly procedure in the numerical order given. 2 Install the drive gear with gear position as shown in figure.
gear
3 screw (PTPWH2.6 � 16)
5 two screws (PTPWH2.6 � 7)
front side
4 sub chassis (2130)
1 Install the control cam with gear position as shown in figure.
gear
front side
10
|
|
|
> |
|
