NOTES 1) For standardisation reasons : * only the coated soleplate will be supplied for those types, which are suitable for 110 - 127 V. * only the stainless steel sole plate wil be supplied for those types, which are suitable for 220 - 240 V. * no info about type number and voltage has been stamped onto the typeplate. When replacing the type plate, engrave at least type number and voltage into the type plate with a sharp object. * tank 16 has been provided with the tank valve 101 of the dripstop version of the HI 282/284 resp. HI 292/294. The black rubber stopper 102, belonging to the tank of the H1272/274, has been included as a spare part. When replacing the water tank, always provide the tank with the rubber stopper 102. 2) Parts, with numbers from 100 and higher, cannot be ordered separately. 3) After the product has been repaired, it should function properly and has to meet the safety requirements and legal regulations as laid down and officialy established at this moment.
ADJUSTMENT AND CONTROLS Thermostat 20 Thermostat 20, fitted to the sole plate 21 has already been adjusted by the supplier and secured by glue. To avoid malfunction of the iron, NEVER readjust the thermostat. Adjustment Thermostat 20, supplied as a spare part. Connect the connecting strips to an Ohm meter. Set the thermostat stopper to the position as indicated in fig. 1. Turn the adjusting screw ( R ) clockwise or anti-clockwise until the Ohm meter indicates � 0 �. ( the contacts are closed ). Then turn the adjusting screw clockwise until the Ohm meter indicates � and the contacts have only just been opened. You hear a � click �. While loosely turning the thermostat stopper, check if the thermostat switches in the position as indicated in fig. 1. Secure the adjusting screw by glue. After adjusting the thermostat, always check the temperature of the soleplate, with the dial set to MAX. pos. ( 215 ± 25 °C ). For location of the test point, see fig. 2. The temperature must be measured, after the iron has been connected to the mains for at least 15 min. The max. temperature shall not be higher than 240 °C.
2
N FUSE RESISTOR INPUT LAMP L E HI 272, HI 274 HEATING UNIT
Testpoint
THERMOSTAT
PCS 88 667
|
|
|
> |
|
