This manual is accurate and of high quality. It is only volume 2 of the service manual. This is schematic, parts lists, and exploded mechanical drawings. The theory of operation and the diss-assembly instructions are in volume 1. The unit can be tricky to dis-assemble portions of so the volume 1 manual can be important. The product description of the manual is accurate but it does not say anything about volume 1 and the image of the front page does clearly say Volume 2.
�
REMOVAL OF THE FRONT C.B.
Release
1. Remove 2 screws on the FRONT C.B. Hook 2. Release the 2 hooks and slide the FRONT C.B out of the slots in the direction of the arrow.
FRONT C.B
FROM MAIN C.B
Slots
FRONT C.B
�
REMOVAL OF THE BUILT-IN MIC
1. Remove 4 screws of the WINDOW, TUN. 2. Release the catches of the WINDOW, TUN by pushing in the directions of white arrows. 3. Remove the WINDOW, TUN in the black arrow direction. 4. Remove 2 screws of the COVER, MIC. 5. Remove the COVER, MIC. 6. Remove the CUSHION, MIC. 7. Remove the NET, MIC and the HLDR, MIC and the BUILT-IN, MIC can be removed.
COVER, MIC CUSHION, MIC MIC HLDR, MIC
NET, MIC Ensure stress free wires
