SPECIFICATIONS
Maximum output: Power source: Maximum dimensions: 4 mW + 4 mW (EIAJ 16 ohms) DC 3 V using two R6 (size AA) batteries 91.5 (W) x 116.5 (H) x 33.0 (D) mm (35/8 x 45/8 x 15/16 in.) (excluding projecting parts and control) Approx.109 g (3.8 oz) (excluding batteries)
Weight
� Design and specifications are subject to change without notice. � Dolby noise reduction manufactured under license from Dolby Laboratories Licensing Corporation. "DOLBY" and the double-D symbol Laboratories Licensing Corporation. are trademarks of Dolby
ACCESSORIES / PACKAGE LIST
REF. NO. PART NO.
KANRI NO.
DESCRIPTION
1 2 2 3 3
8B-HRL-046-010 87-B30-431-010 87-B30-434-010 8B-HKA-901-010 8B-HKA-902-010
CLIP,BELT J034N HEADPHONE,HP-M029(BL) <Y1BLC,Y1LC> HEADPHONE,HP-M029(DG) <Y1SC> IB,Y(EGFSI)-C IB,Y(EDPOHCZ)-C
�2�
|
|
|
> |
|
