SPECIFICATIONS
Maximum output: Load impedance: Power source: Battery life (EIAJ 1 mW output): Maximum outside dimensions: Weight 4 mW + 4 mW (EIAJ 16 ohms) 16 � 32 ohms DC 3V using two R6 (AA) dry cell batteries, AC house current using the optional AC adaptor AC-D302 Aprox. 24 hours using two LR6 (AA) alkaline batteries 112.9 (W) x 84 (H) x 29.3 (D) mm (excluding projecting parts and controls) (4 1/ x 3 3/ x 1 3/ in.)
2 8 16
Approx.124g (4.3 oz) excluding batteries
� Dolby noise reduction manufactured under license from Dolby Laboratories Licensing Corporation. �DOLBY� and the double-D symbol Laboratories Licensing Corporation. are trademarks of Dolby
� Design and specifications are subject to change without notice.
DISASSEMBLY INSTRUCTION
1) Remove the 2 screws. 2) Open the battery lid. 3) Release the hooks in the order of 1 - 8 . * Releasing hook 3 : After releasing hooks 1 and 2 , push the center frame (with the marks) to release hook 3 .
5 6
4 Battery Lid Screw
7
1 8
Screw
2
3
2
|
|
|
> |
|
