Pin No.
44 45 46 47 48
Pin Name
F.F/REW POWER ON P-SNSR DET EJECT SW BS MODE IN
I/O
O O I I I
Description
H : MS-SENS L level, L : MS-SENS H level. H : POWER ON, L : POWER OFF.
H : Observation input from photo sensor, L : Ignorance input from photo sensor.
H : Normal action, L : Eject SW turns on. H : Continues playback. BS enable, L : Auto reverse playback. BS disable.
ADJUSTMENT
1. Tape Speed Adjustment Settings : � Test tape : TTA � 100 (Tape center) � Test point : Phones Jack (J101) � Adjustment location : SFR301 � DSL : OFF � Tape selector : NORMAL � Volume : MAX Method : Play back the test tape and adjust SFR301 so that the frequency becomes 3015 Hz ± 10 Hz. Then confirm WOW is less than 0.52 % (RMS).
� 10 �
|
|
|
> |
|
