REASSEMBLE OF CASSEITE LID SPRING. (T-SPRING) 1. First, insert the right cassette foot in. 2. Insert@ into the hole on the cassette foot. 3. Fix @ onto the Frame center indicated by arrow. 4. Fix @ as shown in diagram. 5. Lastly, fix the left cassette foot.
Cassette Lid Frame Centre
Ekure this end is inserted inside the slot of the Frame Centre
q
REPLACEMENT OF STATIC SHEET. 1. Stick the black adhesive static sheet onto the MAIN C.B. such that it covers the 3 belt clip holes.
