is part of the manual is very useful for repairing
Here are circuit diagrams
if there is damage, I recommend using this part of the
a complete list of circuit boards and components
SPECIFICATIONS
Frequency range: For using in North and South America AM: 530 � 1,710 kHz (10 kHz step) FM1,FM2: 87.5 � 108.1 MHz (200 kHz step) For using in Europe and other countries AM: 531 � 1,602 kHz (9 kHz step) FM1,FM2: 87.5 � 108 MHz (50 kHz step) Maximum output: 15 mW + 15 mW (EIAJ/32 �) Power source: DC 3 V using two R6 (size AA) dry cell batteries Battery life (EIAJ 1 mW output): Approx. 7 hours using R6P (size AA) manganese batteries Approx. 22 hours using LR6 (size AA) alkaline batteries Maximum dimensions: 116.7 (W) x 91.5 (H) x 35 (D) mm (45/ x 35/ x 17/ in.)
8 8 16
Weight
Approx.142 g (4.97 oz) (excluding batteries)
� Design and specifications are subject to change without notice.
ACCESSORIES / PACKAGE LIST
REF. NO. PART NO. KANRI NO. DESCRIPTION
1 1 2 3 3
8A-HRC-913-010 8A-HRC-915-010 84-447-019-310 87-B30-258-010 87-B30-150-210
IB,YH(EC)-C<YH> IB,YJ(EC)-IN<YJ> CLIP,BELT HEADPHONE,HP-M007B(F)<YH> HEADPHONE,HP-M006A(F)<YJ>
2
|
|
|
> |
|
