SECTION 1 SERVICING NOTE
HOW TO OPEN THE DISC TRAY WHEN POWER SWITCH TURNS OFF
1 Remove the Case.
3 Pull-out the disc tray.
2 Turn the cam to the direction of arrow.
Note for Installation (ROTARY ENCODER)
BU cam
Note:When attaching the Base unit, Insert the section A into the groove of BU cam.
Section A Groove
Note:When attaching the BU cam, engage the Rotary encoder switch as shown in the figure.
4
|
|
 |
> |
|
