AIWA HTD590
Service Manual


Tweet about this product and get $1.00 of store credit for instant use!
  • Contains Circuit Diagrams
  • Download
  • PDF Format
  • Complete manual
  • Language: English
Price: $4.99

Description of AIWA HTD590 Service Manual

Complete service manual in digital format (PDF File). Service manuals usually contains circuit diagrams, printed circuit boards, repair tips, wiring diagrams, block diagrams and parts list. Service Manual ( sometimes called Repair Manual ) is used mainly by technicians.

If You just want to know how to use Your tv, video, mp3 player etc. You should look for Owner's Manual. After placing order we'll send You download instructions on Your email address.

The manual is available in languages: English

Not yet ready
You must purchase it first

Customer Reviews
There are currently no product reviews.
Other Reviews
 CDI205/00 PHILIPS Service Manual by Jac Janssen;
Fast delivery and good quality manual. Very easily downloadable from a given url. Will be pleased to buy again from this seller.
 V1700 GRUNDIG Service Manual by giovanni de angelis;
Ottimo manuale, grafica ferfetta invio rapidissimo. Altissimo livello!!!!!
 SC5330 SANSUI Service Manual by Butch Williams;
Great PDF easy to read good info needed for replacment of belts and assembly and specs.
 VSG51 AKAI Service Manual by Peter Kok;
complete and unabridged very good quality easy to download. recieved in two days.
 PT-60LCX64 PANASONIC Service Manual by miles hearn;
Awesome manual. Complete diagrams of all board assemblies as well as how to get to each part of the t.v. down to the individual screws and their locations. Get it.

Text excerpt from page 22 (click to view)
ELECTRICAL ADJUSTMENT

TUNER C.B
FFE801

3

6

IC BLOCK DIAGRAM IC, BU4094BCF

TP6

4

L772 TP1 L981

L771

TP3 TP2 1/3 TP4

IC771 TP3 TP4 TP5

4
< TUNER SECTION >
1. Clock Frequency Check Settings: � Test point: TP2 (CLK IC770 pin30) Method: Set to AM 1602kHz and check that the test point becomes 2052kHz±45Hz. 2. AM VT Check Settings: � Test point: TP1 (VT) Method: Set to AM 1710kHz and check that the test point is less than 8.5V. Then set to AM 530kHz and check that the test point is more than 0.6V. 3. AM IF Adjustment Settings: � Test point: TP5, TP6 L772 .............................................. 450kHz 4. AM Tracking Adjustment Settings: � Test point: TP5, TP6 � Adjustment location: L981 (1/3) Method: Set to AM 999kHz and adjust L981 so that the test point becomes maximum. 5. FM VT Check Settings: � Test point: TP1 (VT) Method: Set to FM 87.5MHz, 108.0MHz and check that the test point is more than 0.5V (87.5MHz) and less than 8.0V (108.0MHz). 6. DC Balance/Mono Distortion Adjustment Settings: � Test point: TP3, TP4 � Adjustment location: L771 � Input level: 60dB Method: Set to FM 98.0MHz and adjust L771 so that the voltage between TP3 and TP4 becomes 0V±0.04V. Next, check that the distortion is less than 1.3%.

IC, M62431FP

PRACTICAL SERVICE FIGURE
< TUNER SECTION >
<FM SECTION> Signal to noise ratio: Distortion: (Input: 60dB) Stereo separation: Intermediate frequency: <AM SECTION> Sensitivity: (S/N 20dB) Signal to noise ratio: (Input: 74dB) Distortion: Intermediate frequency: More than 62dB (at 98.0MHz) Less than 2.0% (at 98.0MHz) More than 22dB (at 98.0MHz) 10.7MHz

Less than 60dB (at 600kHz) Less than 58dB (at 1000/1400kHz) More than 36dB (at 1000kHz) Less than 1.5% (at 1000kHz) 450kHz

IC, BA3880S

37

38
