Text excerpt from page 43 (click to view)
Adjustment Using the SET UP Button
The SET UP button allows you to make the following adjustments.
Selecting the MULTI CH IN video input
This parameter lets you specify the video input to be used with the audio signals from the MULTI CH IN jack. The MULTI CH IN video input is set to DVD/LD by default.
1 2 3
Press SET UP. Press the cursor buttons ( � MULTI CH IN VISUAL�. or ) to select
Turn the jog dial to select the video input you want.
Set the display to turn off
This parameter lets you specify whether or not the display turns off when you press the DIMMER button several times. When �WIDE� is selected, you can set the display to turn off, but when �NARROW� is selected, you cannot set the display to turn off. The default setting is set to �NARROW�.
Other Operations
1 2 3
Press SET UP. Press the cursor buttons ( RANGE�. or ) to select �DIM.
Turn the jog dial to select �NARROW� or �WIDE�.
