HTP102-SW
PARTS LIST
NOTES: � Parts marked by "NSP" are generally unavailable because they are not in our Master Spare Parts List. � The � �mark found on some component parts indicates the importance of the safety factor of the part. Therefore, when replacing, be sure to use parts of identical designation.
For Packing
Mark No. Description Parts No. Mark No. Description Parts No.
Low Frequency Trans Screw for Trans Logo (HTP Subwoofer) Front Port Ring (Plastic) Rear Port Ring (Plastic) Paper Port Tube Foot w/Non-Skid Pad Screw for Foot Terminal with Network Screw for Terminal Speaker Wire (Dark Blue, 10�, 18 GA) Speaker Wire (Red, 10�, 18 GA)
20-207A/XL 221904 255101 254306 254346 255136 250111 222539 255121 250146 250626 250631
Packing Case Corner Pad Assy. Bottom Corner Pad Assy. Top Polybag
255047 255052 256124 255067
SCHEMATIC DIAGRAM
POLYSWITCH RXE135 6.0 mH INPUT (L)
+
#205 FEMALE, RED
OUTPUT TO SUBWOOFER (L)
-
#110 FEMALE, BLACK
OUTPUT TO FRONT SPK.(L) TERMINAL CUP
POLYSWITCH RXE135 6.0 mH INPUT (R)
+
#205 FEMALE, RED
OUTPUT TO SUBWOOFER (R)
-
#110 FEMALE, BLACK
OUTPUT TO FRONT SPK.(R) TERMINAL CUP
2
|
|
|
> |
|
