Adjustment procedure
I Adjusting the cut-off frequency and volume
POWERED SUBWOOFER
FREQUENCY OUTPUT LEVEL
Although it is recommended to set the cut-off frequency and output level settings as high as possible, it is difficult to notice the extremely low frequency bass sounds. This makes it possible to accidentally set the volume level too high. In order to prevent this, back the levels down just a bit to ensure the proper balance. Note: Make sure that the input levels do not reach excessive levels. The HTP-2 is designed for playing back music at a normal volume, but if the input levels are set to enormous levels, it may damage the speakers. Also, always first lower the volume at the amplifier before changing the settings of any switches to prevent accidental damage.
50Hz
200Hz
MIN
MAX
Recommended level for the HTP-2 package system
Use the cut-off frequency (FREQUENCY) and volume (OUTPUT LEVEL) knobs on the front of the subwoofer (SL105) and adjust the levels to the desired level in accordance with the layout of your room and the positioning of all your components. If the playback frequency range and volume of the subwoofer are not set to proper levels, distortions in the playback characteristics can result.
When using only the subwoofer (SL-105)
I Connection with a preamplifier
Preamplifier Output terminals
L R
Speaker (R)
Receiver (Amplifier) Speaker terminals
+
R
Speaker (L)
_
_
L
+
To power amplifier
SL-105
SPEAKER LEVEL
(Not supplied)
SPEAKER LEVEL
+
R
_
_
L
+
+
R
_
_
L
+
LINE INPUT
AUTO STANDBY
AMP/RECEIVER
INPUT FROM
INPUT
FROM AMP/RECEIVER
OUTPUT
L
(MONO)
TO SPEAKERS
+
OFF ON
R
_
_
L
+
OUTPUT
TO SPEAKERS
+
_
R
_
L
+
R
SL-105
Note: With an ordinary preamplifier having two output channels, connect both the Right and Left jacks.
For details on how to connect the speaker cables, see the previous page. Notes: � When connecting the speaker cables, be sure not to mistake the (+) and (-) and the L (left) and R (left). If the speaker cables are connecting incorrectly, there will be a loss of fidelity in the bass sound ranges. � The speakers connected to the SL-105 speaker-level output (OUTPUT TO SPEAKERS) terminals must have an impedance equal to or greater than the rating indicated on the amplifier connected to the speakerlevel input (INPUT FROM AMP/ RECEIVER) terminals. Otherwise, amplifier damage may occur. � Do not use BTL (Balanced Transformer-Less) type amplifiers. Using a BTL amplifier may cause damage to both the amplifier and the subwoofer. Ordinary amplifiers are not BTL amplifiers. For details, see the amplifier�s instruction manual.
I Connection to receiver�s (amplifier�s) speaker terminals
1. Using speaker cables and the speaker cables that came with your speakers, connect the SL-105 speaker-level input (INPUT FROM AMP/ RECEIVER) terminals and the amplifier�s speaker terminals. 2. Connect the Right and Left speakers to the SL-105 speaker-level output (OUTPUT TO SPEAKERS) terminals.
7
