ICD-MS515 SECTION 5 EXPLODED VIEWS
NOTE: � -XX, -X mean standardized parts, so they may have some differences from the original one. � Items marked �*� are not stocked since they are seldom required for routine service. Some delay should be anticipated when ordering these items. � � The mechanical parts with no reference number in the exploded views are not supplied. Hardware (# mark) list and accessories and packing materials are given in the last of this parts list.
5-1. FRONT CABINET SECTION
Rear Cabinet section
9
10
6 4
7
not supplied
11 12
26 25 3
LCD1 not supplied
5
21 5 23 17 22 15 14 16 18 24 2 13
20
19
1
Ref. No. 1 2 3 4 5 *6 7 9 10 11 12 13 14
Part No. 3-234-449-15 A-3174-485-A 3-240-261-01 3-236-038-01 3-318-203-21 A-3021-827-A 3-239-165-01 3-238-736-01 3-236-043-01 3-236-021-01
Description SCREW (M1.4) FRONT BLOCK ASSY SHEET (BLIND) SHEET (LCD), ADHESIVE SCREW (B1.7X8), TAPPING MAIN BOARD, COMPLETE SHEET (JACK), INSULATING PAPER (E), SHIELD ORNAMENT (MIC) WINDOW (LED)
Remarks
Ref. No. 15 16 17 18 19 20 21 22 23 24 25 26 LCD1
Part No. 3-236-475-01 3-236-030-01 3-236-459-01 A-3174-172-A 3-236-480-01 3-239-897-01 3-240-324-01 3-241-209-01 3-239-067-01 3-239-070-01
Description COVER (BATTERY TERMINAL) LID (M) SPRING (LID) MECH BLOCK ASSY, EJECT SPRING (SLIDER EJ), TENSION CUSHION (SD) CUSHION (EL) PLATE, GROUND SHEET (EJECT) SPACER (EJECT)
Remarks
3-236-033-01 CHASSIS (PWB) 3-318-382-02 SCREW (1.7), TAPPING 3-236-456-01 BRACKET
X-3381-982-1 EL SUB ASSY 3-239-894-01 SHEET (SD-A) 1-477-070-11 INDICATOR UNIT, LIQUID CRYSTAL
30
|
|
|
> |
|
