CHAPTER 6 FIXING SYSTEM
Cleaning the Silicone Oil Pan Be sure to remove the silicone oil collecting in the oil pan [7] (found under the web feed roller). Further, if silicone oil should drip, be sure to wipe it clean.
[7]
F06-402-04
4.2.2 Mounting the Fixing Web
Mount the fixing web by reversing the steps used to remove it. 1) Wind the web [2] around the web takeup roller [1] two or three times while making sure that the arm guide plate [3] will be outside the take-up roller (when attaching to the front). At this time, check to make sure that the area of contact with the roller is impregnated with oil.
[3] [1]
[2]
F06-402-05 Check to make sure that the fixing web is not askew and it is not slack or wrinkled. In addition, be sure that the web is wound and attached as shown.
Take-up roller
Feed roller
F06-402-06
COPYRIGHT © 2000 CANON INC. 2000 2000 2000 2000 CANON iR5000/iR6000 REV.0 JULY 2000
