SERVICE MODE
COPIER>ADJUST
SP-T-1N
Use it to adjust the output occurring while thick paper/single-sided copy (or the 1st side of a double-sided copy) is being fed in a normal-humidity environment.
SP-T-2N
Use it to adjust the output occurring while thick paper/double-sided copy (i.e., its 2nd side) is being fed in a normal-humidity environment.
SP-OHP-N
Use it to adjust the output occurring while a transparency is being fed in a normal-humidity environment.
SP-S1-1N
Use it to adjust the output occurring while special paper/single-sided copy (or the 1st side of a double-sided copy) is being fed in a normal-humidity environment.
SP-PO-1N
Use it to adjust the output of a postcard/single-sided copy (or the 1st side of a double-sided copy) is being fed in a normal-humidity environment.
SP-N1H
Use it to adjust the output occurring while plain paper/single-sided copy (1st side of a double-sided copy) is being fed in a high-humidity environment.
SP-N2H
Use it to adjust the output occurring while plain paper/double-sided copy (i.e., its 2nd side) is being fed in a high-humidity environment.
SP-T-1H
Use it to adjust the output occurring while thick paper/single-sided copy (or the 1st side of a double-sided copy) is being fed in a high-humidity environment.
SP-T-2H
Use it to adjust the output occurring while plain paper/double-sided copy (or the 2nd side of a double-sided copy) is being fed in a high-humidity environment.
SP-OHP-H
Use it to adjust the output occurring while a transparency is being fed in a high-humidity environment.
SP-S1-1H
Use it to adjust the output occurring while special paper/single-sided copy (or the 1st side of a double-sided copy) is being fed in a high-humidity environment. S-66
 $4.99 IRC2050 CANON
Parts Catalog Parts Catalog only. It's available in PDF format. Useful, if Your equipment is broken and You need t…
|
|
|
> |
|
