8. TO SAVE THE DATA TO OTHER UNIT
It is commonly necessary to save all data stored in the customer's unit before repairing it. For this purpose, you can transfer the data of the JD-6500 or C-320 unit to another unit using the following procedure. (1) To reset the receiving unit Please reset the unit used to receive the data from the customer's unit according to the method mentioned in section 3. (2) To connect transmission unit with receiving unit Please remove the covers of battery compartments from both the transmission unit and the receiving unit, and connect one with another as shown in the figures below:
Button battery
UNIT 2
CP51 51K 1K MA704
RESET
DP1 Checkpad CP50 CP52 CP51 GND DTC114YK
CP50
DP1
CP52 Rx MA704
UNIT 1 DP1 CP50
DTC 114YK
GND
Tx CP51 51K MA704 CP52 MA704 Rx 1K
3 pins cable
� 19 �
Tx
|
|
|
> |
|
