Getting Started
Installing the TV
Carrying Your TV
Carrying the TV requires at least two people. Do not hold by the pedestal or the front panel of the TV. Doing so may cause these parts to break off. When moving the TV, place one hand in the hole on the lower portion of the TV while supporting the top with the other hand, as shown in the illustration below.
Getting Started
Do not grasp the pedestal or the front panel of the TV.
If you have connected cables and cords, be sure to unplug them before moving the TV.
Take Precaution during Installation
To ensure the safety of children and the TV, keep children away from the TV during installation. Climbing on or pushing the TV or its stand may cause it to fall and damage the TV. As a protective measure, secure the TV as follows.
Using the TV stand with support belts �
Preventing the TV from Toppling Over
Sony strongly recommends using the TV stand SU-RS11M (for KDS50A2000)/SU-RS11X (for KDS-55A2000, KDS-60A2000) with a support belt designed for your TV.
�
When using the SU-RS11M (for KDS-50A2000)/SU-RS11X (for KDS55A2000, KDS-60A2000) stand for your TV, you must use the support belt.
11
|
|
|
> |
|
