De bediening van de extra apparatuur
1 2 3
Sluit de extra apparatuur op de juiste ingang van het TV toestel aan volgens de aanwijzingen op bladzijde 28. Zet het aangesloten apparaat aan. Druk om het beeld van het aangesloten apparaat weer te geven herhaaldelijk op de totdat het juiste symbool voor deze ingang in beeld verschijnt. Ingangssignalen 2 � Ingangssignaal voor audio / video via de euroscart A. � Ingangssignaal RGB via de euroscart A. Dit symbool komt alleen dan in beeld als er een RGB bron is aangesloten. 3
S
toets
Symbool 1 of
� Ingangssignaal voor audio / video via de euroscart B. � Ingangssignaal S-video via euroscart B. � Ingangssignaal video via de phono aansluiting D en ingangssignaal audio via C. � Ingangssignaal S-video via de S-video aansluiting E en audiosignaal via C. � Ingangssignaal RGB via de aansluitingen Y/G, PB/CB/B, PR/CR/R en de Haansluitingen HD, VD, en het audio-ingangssignaal via G.
3 4
S
4 5
� Selecteer als uw apparatuur op de euroscart 3/ S , of op het 4/ S 4, 5 contact is aangesloten het ingangssignaal van het aangesloten apparaat met behulp van de optie �AV3-ingang,� �AV4-ingang,� of �AV5-ingang� in het menu �Kenmerken� (bladzijde 20). � Selecteer als uw apparatuur op de 5 aansluitingen en de uitgangen van het RGB signaal is aangesloten de RGB-stand in het menu �Kenmerken� (bladzijde 20).
4
Druk om terug te keren naar het gewone TV beeld op de afstandsbediening.
toets van de
Voor mono-apparatuur: Verbind de phono plug met de L/G/S/I steker en kies het ingangssignaal 4 of S 4 volgens de bovenstaande aanwijzingen. Ga tenslotte naar het hoofdstuk �Geluidsinstellingen� van deze handleiding en selecteer �2-talig� �A� op het geluidsmenuscherm.
30
Aanvullende informatie
|
|
|
> |
|
