Inserting and Removing a Memory Stick
If you are using a Memory Stick Duo, see �Inserting the Memory Stick Duo� on page 70.
Inserting a Memory Stick
1 Locate the Memory Stick slot and insert the Memory Stick into the
Memory Stick slot as illustrated below. When inserted properly, it should slide in with little resistance and click into place.
PRO
Be sure to insert the Memory Stick in the correct direction. If the Memory Stick is forced in the wrong way, it may become damaged. Insert only Memory Stick media into the Memory Stick slot. Attempting to insert other objects into the slot may damage the TV.
To remove the Memory Stick, see �Removing a Memory Stick� on page 71.
Memory Stick
69
|
