Stabilizing the monitor Using the brackets
the supplied brackets. After setting up, secure the monitor to a wall, etc. with
For customers in Japan and the U.S. only Using the support belts (not supplied)
You can also use the BLT-R10 support belt for the monitor stand (not supplied) to secure the monitor. We recommend you use the SU-90 monitor stand with which the support belts are supplied.
Step 2: Hookup
Using the rear RGB 1 IN connector
Rear of the monitor
1
Mount the two supplied brackets with the screws to the upper rear sides of the monitor.
RGB 1 IN
About the SU-90 monitor stand (not supplied) The dimensions of the stand are 1,050 x 700 x 630 mm (41 3/8 x 27 5/8 x 24 7/8 inches) (width/height/depth). Before you purchase this stand, refer to the dimensions above and check the size of the area where the stand will be installed.
Bracket (supplied)
AUDIO
RGB
L
Before making the connection, turn off the power and disconnect the AC power cords of the monitor and the equipment to be connected. Refer to the instruction manual of the equipment you connect.
R
RGB OUT
AUDIO
R L
RGB
Customers in Japan should use the stand SU-90T. Customers in the U.S. should use the stand SU-90U.
Connecting to an IBM PC/AT or compatible computer
Connect the RGB 2 IN connector on the front or the RGB 1 IN connector at the rear of the monitor to the video output of the computer using the supplied RGB signal cable (D-sub 15 pin � D-sub 15 pin). Use an audio connecting cord (not supplied) for the audio connections.
Rear
2
Pass a strong cord or a chain through each bracket mounted in step 1, and then secure it to a wall or a pillar, etc.
Audio connecting cord (phono plug � 2 � stereo miniplug) (not supplied)
or
RGB signal cable (supplied)
GB
� 9 �
Using the front RGB 2 IN connector
Front of the monitor HD15�HD15 adaptor (supplied)*
RGB 2 IN
Front
RGB AUDIO S VIDEO
to audio output
Male side (without the No.9 pin) to video output
IBM PC/AT or compatible computer
RGB signal cable (supplied) or Audio connecting cord (stereo miniplug � stereo miniplug) (not supplied) HD15�HD15 adaptor (supplied)*
* The HD15�HD15 adaptor (supplied) may be needed for some models. The male side (without the No. 9 pin) of the adaptor should be connected to the computer.
For customers using the supplied HD15�HD15 adaptor This monitor uses a No. 9 pin in the video signal connector for DDC1 and DDC2B compatibility. Some PC systems which are not compatible with either DDC1 or DDC2B may not accept the No. 9 pin. If you are not sure whether your PC system accepts the No. 9 pin or not, use the HD15 (Female) � HD15 (Male without the No. 9 pin) adapter (supplied).
to audio output
Male side (without the No.9 pin) to video output
IBM PC/AT or compatible computer
6-GB
Getting Started
Getting Started
7-GB
|
|
|
> |
|
