KP-43T70K/43T70T/48VS70K/53VS70K/53VS70T
RM-Y906K RM-Y906 RM-Y906K RM-Y906K RM-Y906
[GREEN REGISTRATION ADJUSTMENT]
<GREEN CENTER> 1. Select GRN CENT with the 1and 4 keys on the remote commander. 2. Adjust the crosshatch line goes straight vertically and horizontally with the joystick on the remote commander.
<FINE ADJUSTMENT> 1. Press 9 key on the remote commander to shift to the fine adjustment mode. The green marker (in the GRN mode) appears on the center of the screen. 2. Use the 1and 4 keys or the joystick on the remote commander, move the marker (see below) everywhere you want to adjust and adjust with the joystic keys on the remote commander. Marker movement by the 1 and 4 keys:
GRN CENT
000
000
<GREEN SKEW> 1. Select GRN SKEW with the 1and 4 keys on the remote commander. 2. Adjust the crosshatch line goes straight vertically and horizontally with the joystick on the remote commander.
Press once the joystick the marker turns sreen to white. Then you can move the marker up and down ,left and right.
GRN SKEW
000
000
3. Press 9 key on the remote commander to shift to the rough adjustment mode. <GREEN PINCUSHION> 1. Select GRN PIN with the 1and 4 keys on the remote commander. 2. Adjust the crosshatch line goes straight vertically and horizontally with the joystick on the remote commander.
GRN PIN
XXXX
000
GRN PIN
� 35 �
|
|
|
> |
|
