2-5. J BOARD REMOVAL
1 Push the claw in the direction of the arrow and remove.
2-6. J SHIELD REMOVAL
1 Push the claw in the direction of the arrow and remove. 3 Remove the shield in the direction of the arrow.
2 Push the claw in the direction of the arrow and remove.
2 Pull the Board in the direction of the arrow and remove.
2-7. B1 BOARD REMOVAL
NOTE
All other boards are removed in a similar manner to those shown
18
|
|
|
> |
|
