(8) Remove two scrwes and take the head out. � To adjust the head position, insert small screw driver through the hole on plastic shaft then turn the adjustment screw. First, turn the screw clockwise all the way then turn it counterclockwise 2 and 1/4 turns. Head will be placed in the center. Fine adjust the head position by turning the screw little by little and checking the result print. � When you assemble the head, remove caution plate for ink ribbon setting and insert the FPC cable through the hole.
(9) Depending on head rank printed on FPC cable, short or open the soldering pad on PCB 701 SUB as shown below. Head Rank Pad RNK1 Pad RNK2 Pad RNK3 Pad RNK4 0000 1111 2222 3333 4444 5555 6666 7777 8888 9999 Open Short Open Short Open Short Open Short Open Short Open Open Short Short Open Open Short Short Open Open Open Open Open Open Short Short Short Short Open Open Open Open Open Open Open Open Open Open Short Short PCB 701 SUB
