TAPE MECHANISM PARTS LIST-1/1
REF. NO 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30
PART NO.
KANRI NO.
DESCRIPTION PULLEY,MOTOR BELT,SBU MAIN2 EPDM FLY-WHL ASSY,L GEAR,REW GEAR,REEL GEAR,CAM(*) FLY-WHL ASSY,R GEAR,FR LVR,FR SLIP DISK ASSY 2 GEAR,PLAY GEAR,IDLER RING MAGNET 4 LVR,TRIG SPR-E,TRIG 2 SPR-E,LVR DIR SPR-T,FR 60 CHAS ASSY,FPC SOL ASSY,27 SO LVR ASSY,PINCH L2 SPR-T,PINCH L PLATE,LINK2 SPR-C,BT LVR,DIR SPR-T,DIR SPR-T,BRG REEL TABLE CHAS,HEAD SPR-T,LINK SPR-E,HB
REF. NO 31 32 33 34 35 36 37 38 39 40
PART NO.
KANRI NO.
DESCRIPTION LVR,REC(*) SPR-T,PINCH R SPR-T,CAS SPR-C,BT L LVR,CAS LVR,STOP BELT,FR 4 SPR-T,HEAD 2 GUIDE,TAPE PLATE,HEAD HLDR,HEAD HEAD,RPH YK56R-BF414 GEAR,H T LVR,PLAY(*) LVR ASSY,PINCH R2 SH,1.63-3.2-0.5 SLT U+2.6-3 UT2+2.6-6 GLD W-P,2.08-8-0.4-SLIP SH 1.75-3.6-0.5 SLT PW 2.16-6-0.4 S-SCREW,AZIMUTH L S-SCREW,TG S-SCREW,SHILD PLATE V+1.6-7
82-ZM1-247-210 82-ZM1-354-010 82-ZM1-234-310 82-ZM1-226-010 82-ZM1-216-510 82-ZM1-221-310 82-ZM1-237-610 82-ZM1-225-210 82-ZM1-224-410 82-ZM3-333-310 82-ZM1-223-010 82-ZM1-220-210 82-ZM3-616-010 82-ZM1-227-310 82-ZM1-305-210 82-ZM1-255-310 82-ZM1-322-010 82-ZM1-358-010 82-ZM3-627-010 82-ZM1-341-210 82-ZM1-258-210 82-ZM1-333-210 82-ZM1-244-510 82-ZM1-266-310 82-ZM1-214-010 82-ZM1-269-210 82-ZM1-217-410 82-ZM1-206-910 82-ZM1-219-110 82-ZM1-218-010
82-ZM1-240-110 82-ZM1-259-210 82-ZM1-257-010 82-ZM1-285-410 82-ZM1-242-010 82-ZM1-243-010 82-ZM1-338-110 82-ZM3-353-010 82-ZM1-207-910 82-ZM1-314-110
41 82-ZM1-208-310 42 87-A90-367-110 43 82-ZM1-210-110 44 82-ZM1-222-310 45 82-ZM1-344-210 46 82-ZM1-288-010 A 87-251-070-410 B 87-741-073-410 C 87-B10-008-010 D 80-ZM6-243-010 E 82-ZM3-334-010 F 86-ZM4-206-110 G 85-ZM3-202-010 H 82-ZM3-222-010 I 80-ZM6-207-010
COLOR NAME TABLE
Basic color symbol Color Basic color symbol Color Basic color symbol Color B Black C Cream D Orange G Green H Gray L Blue LT Transparent Blue N Gold P Pink R Red S Silver ST Titan Silver T Brown V Violet W White WT Transparent White Y Yellow YT Transparent Yellow LM Metallic Blue LL Light Blue GT Transparent Green LD Dark Blue DT Transparent Orange GM Metallic Green YM Metallic Yellow DM Metallic Orange PT Transparent Pink LA Aqua Blue GL Light Green M Wood Patte
-5-
|
