4-6 Cleaning the Rubber Sheet / Paper Feed Roller / Separate Roller
Wipe the Rubber Sheet, the Paper Feed Roller, and the Separate Roller with a clean, soft, dry, lint-free cloth.
Paper Feed Roller
Rubber Sheet
Separate Roller
Figure 1-58 Cleaning the ADF 4-7 Cleaning the Paper Feed Roller
Follow this procedure: 1. Connect the power cord, and power on the machine. 2 Remove any paper from the Auto Sheet Feeder and Cassette. 3 Select the paper source with [Fee Switch]. d 4 Press [Menu] repeatedly until <3 .MAINTENANCE> appear s. 5 Use [Right ursor ] or[Left c cursor ] to sel <ROLLER CLEANING> ect . 6 Press [OK]. The machine starts cleaning the roller. 7 When cleaning has finished, repeat steps 3 to 6 for a total of two times. 8 Load A4- or letter-sizeplain paper in the Auto Sheet Feeder or Cassette and repeat steps 3 to 5 an additional three times.
