Chapter 2: Technical Reference
NOTE
Waste Ink Absorbers This model has a single ink absorber which absorbs waste ink as follows. � Suction waste ink Waste ink sucked from the cap � Maintenance jet waste ink Waste ink from the test firing used to adjust the nozzle condition � Ink detection waste ink Waste ink fired to detect the presence of remaining ink during fax receipt The amount of ink absorbed is counted as a total of all of these. When the counted absorption levels reach 100%, the �CHECK PRINTER� message (error code ##342) will be displayed, and printing will stop to allow the absorber to be changed. To clear the error, it is necessary to replace the absorbers and to reset the waste ink absorption level counts. If there is no other error at this time, any image in the memory will be output automatically. The waste ink absorber should be replaced after this. For the method of resetting the waste ink absorption level counts, see Page 1-49.
2-19
|
|
|
> |
|
