2349-3
HAND SETTING MODE
Hour hand Minute hand
Mode indicator Hour Minutes
When the time shown on the display does not match the analog setting, use this mode to correct the analog setting. 1. Hold down A while in the Hand Setting Mode until the message �SET� start to flash on the display. 2. Each press of D advances the hands 20 seconds. Holding down D advances the hand at high speed. � Note that the hands can be advanced only and cannot be moved back. Take care so you do not go past the setting you want to make. 3. After you set the analog time, press A to exit the setting screen. � Depending on your timing when you operate the D button, the above operation can cause the minute hand timing to become late. If this happens, repeat the above operation to correct the minute hand timing.
CHARACTER LIST
CITY CODE TABLE
GMT City differential Code �11 �10 �9 �8 �7 �6 �11 HNL ANC LAX DEN CHI City HONOLULU ANCHORAGE LOS ANGELES DENVER CHICAGO Other major cities in same time zone PAPEETE NOME SAN FRANCISCO, LAS VEGAS, VANCOUVER, SEATTLE, DAWSON CITY EL PASO, EDMONTON HOUSTON, DALLAS/FORT WORTH, NEW ORLEANS, MEXICO CITY, WINNIPEG MONTREAL, DETROIT, MIAMI, BOSTON, PANAMA CITY, HAVANA, LIMA, BOGOTA LA PAZ, SANTIAGO, PORT OF SPAIN SAO PAULO, BUENOS AIRES, BRASILIA, MONTEVIDEO
�5 �4 �3 �2 �1 0 0
NYC CCS RIO �02 �01 GMT LON
NEW YORK CARACAS RIO DE JANEIRO
LONDON
+1
PAR CAI JRS JED THR DXB KBL KHI DEL DAC RGN BKK
PARIS CAIRO JERUSALEM JEDDAH TEHRAN DUBAI KABUL KARACHI DELHI DHAKA YANGON BANGKOK
DUBLIN, LISBON, CASABLANCA, DAKAR, ABIDJAN MILAN, ROME, MADRID, AMSTERDAM, ALGIERS, HAMBURG, FRANKFURT, VIENNA, STOCKHOLM, BERLIN ATHENS, HELSINKI, ISTANBUL, BEIRUT,DAMASCUS, CAPE TOWN MOSCOW, KUWAIT, RIYADH, ADEN, ADDIS ABABA, NAIROBI SHIRAZ ABU DHABI, MUSCAT MALE MUMBAI, CALCUTTA COLOMBO JAKARTA, PHNOM PENH, HANOI, VIENTIANE SINGAPORE, KUALA LUMPUR, BEIJING,TAIPEI, MANILA, PERTH, ULAANBAATAR SEOUL, PYONGYANG DARWIN MELBOURNE, GUAM, RABAUL PORT VILA CHRISTCHURCH, NADI, NAURU ISLAND
+2 +3 +3.5 +4 +4.5 +5 +5.5 +6 +6.5 +7
+8 +9 +9.5 +10 +11 +12
HKG TYO ADL SYD NOU WLG
HONG KONG TOKYO ADELAIDE SYDNEY NOUMEA WELLINGTON
*Based on data as of December 1999.
