Text excerpt from page 172 (click to view)
Different types of paper may be loaded in the multi-purpose tray. â Load just one type of paper.
â Make sure you are loading paper that meets the paper requirements for the
unit (see page 2-2). Transparencies do not feed correctly. The transparencies may not be loaded correctly. â Make sure you load no more than 50 sheets of transparencies in the multipurpose tray. Repeated paper jams occur. The paper you are using may be causing the jams. â Be sure to fan the paper stack before loading it in the multi-purpose tray (see page 2-12). This keeps the sheets of paper from sticking together.
â Check that the paper you are using and your printing environment are within
the speciï¬cations of the unit (seepage 2-2). Envelopes do not load. Envelopes may not be loaded correctly. â Make sure the envelopes are loaded correctly (see page 2-14).
â Make sure there are no more than 10 envelopes in the multi-purpose tray.
You may need to choose the envelope setting in your printer driver. â Make sure you select the correct envelope size in the Media Type setting in the printer driverâs Page Setup dialog (see page 2-4 in the MultiPASS Desktop Manager Software Guide). The envelopes you are using may not meet the requirements for the unit. â Envelopes must be U.S. Commercial No. 10 or European DL envelopes.
