MACKIE HR824 26 pages English-only Service Manual contains:
1) HR824 technical overview with the description of front and rear panel switches.
2) HR824 specs
3) Block Diagram
4) Wiring Diagram
5) Packaging management
6) Spare part & final assembly list (for PCB rev A and B) + exploded view
7) Test Procedures (where, how to measure voltage...) including Test Point diagram on the PCB.
8) IC and Transistor charts.
Excellent guide: very clear, good scan quality enabling us to print readable diagram :-)
Note:
Mackie HR824 make extensive use of surface mount devices (SMD). Service on the HR824 must
only be undertaken by experienced service technicians with the right tools, experience and patience to perform surface mount rework when needed.
;
This Service manual is very well scanned and its clean to read, no any anti-theft words that un-english could understand. I got my CCD600 working with this manual and it´s clear shematics :)
13) Attach the FL cam gear so that the marking on the FL cam gear is aligned to the center of the worm wheel.
FL cam gear The shaded portion should be coated with grease Marking Worm wheel
Fig-2-6-8 Joint gear 1
Two holes Fig-2-6-11
14) To attach the joint gear 2, align the marking on the joint gear 1 with that on the cam slider.
Joint gear 1
Align the markings
The shaded portion should be coated with grease
Joint gear 2
Fig-2-6-9 FL cam gear (Playback only machines) 12) To attach the joint gear 1, attach it so that cutout of the gear is directed toward the FL cam gear.
Align the markings Fig-2-6-12
Cam slider
15) After parts are replaced, assemble the mechanism by reversing the disassembling procedure.
Cut-out of the gear Joint gear 1
Fig-2-6-10
11
|
|
|
> |
|
