Great copy of the manual, has all information required for servicing,
;
I work at an authorized service center and I can tell if a manual is as it should be. This one is. It may be a scan, but a very good one at that. The interesting part for me was the curcuit diagram which was scanned at high quality, making it as good as the original. I will definitely be back as a customer. I need not say this, but I will: the price was the best. Thank you owner-manuals.com .
 ;
really a very good manual even sometimes the quality is no so good as before still very readible and very very useful!
;
FAST very good and clear a great unexpensive job!!! very recomended for all people who are preofessional or hobbists as me!!!!!!
;
Thank you very much for this Service Manual, it helped us a lot to repair the M-4318!
...BUT: The parts list is missing and the free parts katalog on web isn't complete, so now we don't know the part numbers of the defect parts :(
We had to build them out of a working machine, and need the numbers to reorder the missing parts now.
D. Two-Sided Copying
Copy one side of a 2-sided original. Invert the original so that the same edge faces the front. Invert the copy in the same way (front edge facing the front) and feed it into the cooier. Use dry, uncurled paper. Use paper in the weight range 60 to 120 gl m� When making two-sided copies, only one image can be made on each side of the copy paper. Both overlay and two-sided copies cannot be made on the same sheet of copy paper.
The COPY START key changes from blinking green to orange to indicate that the auto start mechanism has been activated. The copier starts making copies as soon as it enters the standby mode using the selected copy modes. The auto start mechanism may be cancelled by pressrng the CLEAR/STOP or RESET key. G.
Replacing the CT Unit
1) Open the front door. 2) Swing the developing assembly release lever counterclockwise. 3) Pull the developing assembly forward. 4) Grasp the handle of the developing assembly, and gently raise it.
Figure l-5
E. Overlay Copy Operation
By changing the developing assembly, a 2-color copy can be made on the same side of the copy paper. a) Use paper in the range of 60 to 126 g/m� b) When making an overlay copy a maximum of two images can be made on one side of the copy paper. c) Overlay and two-sided copies cannot be made on the same sheet of copy paper. Figure l-6
5) Place the CT unit gently on the developing assembly guide rails and push it in the copier. 6) Shift the developing assembly release lever clockwise until it is horizontal. 7) Close the front door,
F. Auto Start
The auto start mechanism may be made use of while the copier is in the wait mode (COPY START key blinking green); i.e., after it is switched ON or after the standby mode is cancelled. Set a document while the copier is in the wait mode, and select the copy mode; then, press the COPY START key. i. Do not tilt or handle the developing assembly or the CT unit roughly. ii. Do not place the developing assembly or the CT unit on the floor. Be sure to place them in their storage box or in the pedestal of the copier.
COPYAIGHTO 1992 CANONINC
CANON NP.1530 REV.0 FEB.1992 PRlNlEDINJAPAN(IMPAIMEAUJAPON)
1-9
