KAPITEL 4 MECHANIK
1. Vorsicht: Vor der Zerlegung oder dem Zusammenbau des Gerätes ist der Netzstecker zu ziehen. 2. Gelöste Schrauben sollten in Gruppen, nach Länge, Durchmesser und Ausbaubereich aufbewahrt werden. 3. Die Montageschrauben für Massekabel und Varistoren sind mit einer speziellen Unterlegscheibe versehen, die einen guten elektrischen Kontakt sicherstellt. Die Unterlegscheibe mu� beim Zusammenbau wieder verwendet werden. 4. Eine der Montageschrauben an der Rückwand ist mit einer Unterlegscheibe zum Schutz gegen statische Elektrizität versehen. Sie mu� beim Zusammenbau wieder angebracht werden. 5. Wenn möglich, sollte das Gerät nicht mit ausgebauten Komponenten betrieben werden. 6. Der Zusammenbau erfolgt in umgekehrter Reihenfolge der Zerlegungsschritte. 7. Beim Ausbau der Fixiereinheit ist darauf zu achten, da� der Türschalter oder der Hauptschalter ausgeschaltet ist.
I. II. III. IV. V. VI. VII. VIII. IX. X. XI.
AUSSENTEILE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4 - 1 ANTRIEBSSYSTEM . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4 - 10 EINZUGS- / TRANSPORTSYSTEM . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4 - 19 BELICHTUNGSSYSTEM . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4 - 34 BELADUNGSSYSTEM . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4 - 36 ENTWICKLUNGSSYSTEM . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4 - 42 TROMMELREINIGUNGS-SYSTEM . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4 - 46 FIXIERSYSTEM . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4 - 49 DF-A1 AUSSENTEILE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4 - 56 DF-A1 BELICHTUNGSSYSTEM . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4 - 59 DF-A1 ANTRIEBSSYSTEM . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4 - 61
|
|
 |
> |
|
