As the only source for this manual it rather rank quite high since it is well scanned and perfectly readable.
 ;
the manual is in good quality and it's in pdf. manual was send in less then 24h.
regards
mike
;
I would not plug this machine in without finding a manual like this. In addition to setup and normal operating instructions, it has troubleshooting flowcharts, diagrammed mechanical adjustments, and schematics to beat the band. The tech I hand it to would be thrilled to find solder side PCB diagrams with component outlines superimposed, pinouts for every IC chip, and line drawings of transistors, with labeled legs.
As for printing quality, this may be a copy of a copy, but even the finest print when enlarged is very legible. There is a bit of grayed print over a few pages, as if a wet page were placed over it, but the print is still very legible. If you could borrow an original manual and get it printed and bound for 4 to 6 times the cost, you could get better quality. In that case you wouldn't be here. For price, utility, and availability I am rating this manual highly.
;
I received the Manual in a timely manner and it was exactly what I needed.
This is a perfect copy of the Service Manual, The quality is great. I am very
happy. Thank you
;
exactly as they say. Within 24 hours the link to the pages and offcourse it was the right service manual. Super and thanks
CHAPTER 9 INSTALLATION
Step 11
Work Perform the following while toner is being supplied. 1. Remove the screw used to keep the center of the right cover in place, and install the original tray to the machine (right) with two stepped screws. (You will not be using the removed screw.) 2. Attach the mode memory sheet to the cover of the toner supply mouth. Reference: If you find installing the original tray difficult, loosen the two mounting screws and start over.
Remarks
Stepped screws
Original tray
12
Attach the Manual Feed Instructions label to the manual feed tray of the RDF.
Label
13
When the toner supply operation has ended, place the Test Sheet on the copyboard, make copies, and check the copy images. At times, toner can fall from the drum separation claws, soiling the initial ten or so copies. (This phenomenon will disappear as copies are made.) Check to make sure that pick-up from each source is normal. Make two-sided/overlay copies.
� Check to make sure that no abnormal sound is heard. � Check images of copies made at each default ratio. � Check to make sure that as many copies as set are made. � If there is a difference in density between left and right, adjust the height of the rear of the primary charging wire to correct.
14
� Check to make sure that copying operation is normal. � Check to make sure that abnormal noise is not heard. � Check to make sure that paper feeding in the holding tray assembly is normal.
COPYRIGHT © 1997 CANON INC.
CANON NP6350/NP6251 REV. 0 JULY 1997 PRINTED IN JAPAN (IMPRIME AU JAPON)
9-29
