Home >> CANON >> NP6545 Service Manual

 0 item(s) in your cart

CANON NP6545
Service Manual


Tweet about this product and get $1.00 of store credit for instant use!
  • Contains Circuit Diagrams
  • Download
  • PDF Format
  • Complete manual
  • Language: English
Price: $4.99

Description of CANON NP6545 Service Manual

Complete service manual in digital format (PDF File). Service manuals usually contains circuit diagrams, printed circuit boards, repair tips, wiring diagrams, block diagrams and parts list. Service Manual ( sometimes called Repair Manual ) is used mainly by technicians.

If You just want to know how to use Your tv, video, mp3 player etc. You should look for Owner's Manual. After placing order we'll send You download instructions on Your email address.

The manual is available in languages: English

Not yet ready
You must purchase it first

Customer Reviews
There are currently no product reviews.
Other Reviews
 R25 LENCO Service Manual by Ljudevit Krizanec Backer;
Quality scan, great manual. I solved my problem with this manual.
 1720L AKAI Service Manual by Graham Bowman;
The AKAI 1720 model reel to reel tape recorder described in this Manual is quite an old unit - circa late 1960's. As a consequence, the description of the mechanical details - and adjustments thereof - is quite critical. The manual does this quite well. The schematics are also well presented and have detailed PCB overlays. Probably the only negative is that some half-tone detail has been lost from the original manual as it has been scanned in simple B&W.
 SR-803 HITACHI Service Manual by Viktor Müller;
Perfect source for service manuals: fast and professional transaction; high quality, perfect readable and largely scaleable PDF; complete schemes, diagrams and spare part list. Tnx a lot, cu again!!!!
 BEOMASTER 6000 BANG&OLUFSEN Service Manual by Helge Schroeder;
I got your link from a friend and I must say that I am really satisfied with your service. Specially this B&O manual I didn't find anywhere on the web... but you could deliver it :-) . You deliver very fast and the copy is of good quality. So your webpage is bookmarked. Thanks
 CCU-550A SONY Service Manual by Ted Kazmierczak;
This was the Sony CCU-500A Service manual I was looking for. The price was reasonable. The permission to download was quck. I will use Owner-Manual.com for all my manual needs.

Text excerpt from page 88 (click to view)
,,,*� ,_

Primary Current Control To measure the dark area potential (VD) for the first time after power-on, a reference current (setting stored in ROM) is sent to the primary charging assembly, and the potential sensor is used to measure the drum surface potential. The DC controller PCB compares the measurements taken of the drum surface potential and the target potential; if the drum surface potential differs from the target value, the primary charging level control signal (HVTPC) generated by the DC controller ,PCB is corrected. In this way, the corrected current is applied to the primary charging assembly by the high-voltage transformer (HVT). The subsequent measurements are made using the previously corrected value as the reference current, thereby reducing the first copy time. Such measurement and correction are repeated as many as eight times so that the dark area potential (VD) will be as close to the target value as possible. If the potential is not within the allowance after the eighth measurement, the dark area potential will be determined using the eighth correction value. Note: I I�, I I� ) tf the potential is in excess of the control range of the target value�aftec measuring the potential eight times, the,notation�l; will be indicated for �PLMT�(upper limit flag 1� �3, ((4 of the primary current value) in service mode, (*J*). #I(, �8 8, ,I

a.

,I

�,�,

Potential control may be disabled by �POCNT� (display mode; *4*). When done, the primary current value will be 1000 uA in text mode and 800 uA in photo mode.

/--A \

b. Controlling the Intensity of the Scanning Lamp To measure the light-area potential for the first time after power-on, the reference ON voltage (setting stored in ROM) is applied to the scanning lamp. In response, the scanning lamp exposes the standard white plate so that the reflected light is projected to the drum. The potential of the surface of the drum exposed to the light is measured by the potential sensor, and the data is sent to the DC controller PCB. The DC controller PCB compares the measurement and the target value; if the measurement differs from the target value, the intensity adjustment signal (LINT) generated by the DC controller is corrected. The subsequent measurements are taken using the previously corrected value as the reference voltage, thereby reducing the first copy time. The corrected voltages are applied to the scanning lamp by the lamp regulator. Such measurement and correction are repeated as many as eight times so that the light area potential (VLI) will be as close to the target value as possible. However, if the measurement does not fall within the allowance after the eighth measurement, the eighth correction value will be used to determine the intensity of the scanning lamp.

COPYRIGHT@

1997 CANON INC.

CANON NP6045 REV. 1 MAR. 1997 PRINTED IN JAPAN (IMPRIME AU JAPON)

4-3
