ADJUSTMENT � 2 <FRONT>
1
B FRONT C.B
FL901
D983 TP11 (KEY-SCAN) IC901 + L951
3
(GND)
C913
< FRONT SECTION >
1. OSC Adjustment Settings : � Test point : TP11 (KEY-SCAN), (GND) � Adjustment location : L951 Method : Insert AC plug while pressing of "POWER" key and "TUNER" function key. Connect a frequency counter across TP11 and GND. Then adjust L951 so that the test point becomes 92.470Hz ± 0.092Hz. [ Manual Reset ] Make up for RESET after adjustment. * Reset is to press "POWER" key while pressing of "CLEAR(STOP)" key.
