How to Adjust Screen Settings
To launch the on-screen display Main Menu: 1. 2. Press the Menu button 3 on the monitor front panel. The Main Menu will display on the monitor screen. To select an item from the Main Menu, scroll down by pressing the down arrow button 1 located on the monitor front panel. To reverse or back up, press the up arrow button 2. The item to be selected will be highlighted in yellow. Press the Menu button 3 again. 5. 6.
A second-level menu displays and adjustment scale. Use the arrow keys 4 or 5 to select a value on the adjustment scale. Press the Menu button 3 to exit from that adjustment. To exit from the on-screen menu, press the Menu button again.
Press Reset to return the adjustments to their original settings.
Troubleshooting
Special OSD Messages
Special OSD messages will appear on the monitor screen when identifying the following monitor conditions:
s
3.
Monitor is Working out of Scan Range, Change PC Settings Indicates the monitor is unable to operate with the selected input signal. Readjust your video setting to a lower resolution. Monitor in Power Save Mode, Activate Using the PC Indicates the monitor is in one of the power saving modes. Monitor is Working, Check Signal Cable Indicates the video cable may not be plugged into the computer.
s s
1-4
Self Diagnosis
If the screen goes blank and the LED is green, remove any video connections from video connector 1 or 2. You can also turn off the PC. Press the power switch twice to turn the monitor OFF then ON again. Press the right arrow button (contrast increase) before the monitor enters power saving mode. If a color bar pattern appears then it is likely the problem is not the monitor. Please check the condition of your computer. If the color bar pattern does not appear, please inform your service representative of the monitor�s condition. If the power LED is flashing orange, please make note of the frequency of flashing and inform your service representative of this frequency.
12345
Monitor with On-Screen Display
The bar on the bottom of the OSD menu shows the current operating frequency (and resolution if VESA standard).
