CONNECTION AND PREPARATION
Connecting the antenna and the mains cable
1 Insert the telescopic antenna (P 37 only) in the recess on the rear panel. 2 Plug the roof antenna cable or the telescopic antenna into the antenna socket
TV R
_______
EURO-AV
»�« on the television set.
3 Insert the power cord plug in the socket.
Inserting batteries in the remote control
1 Open the battery compartment by removing the lid. 2 Insert battery (type Mignon, 2 x 1.5 V, R6/UM3/AA).
Observe the polarity (marked on the base of the battery compartment). Note: If the television no longer reacts properly to remote control commands, the batteries may be flat. Always remove flat batteries. No liability is accepted for damage resulting from leaking batteries. Environmental note: Batteries, including those which are free of heavy metal, must not be disposed of with household waste. Please dispose of used batteries in an environmentally sound manner. Observe the legal regulations which apply in your area.
OVERVIEW
_______________________________________________________________________
The front of the television set
IO zP
P
Switches the television to stand-by mode. Switches the television on from stand-by mode; preset button for volume and channel selection. Channel selection up; raise volume. Channel select down; lower volume. Headphone jack (3.5 mm ø jack plug, located on the side of P 37)). � Connecting a headphone set deactivates the loudspeakers. Audio input (located on the side of P 37). Video input (located on the side of P 37).
+ �
y
P
VIDEO IN AUDIO IN
y
AUDIO IN VIDEO IN
4
|
|
|
> |
|
