CHAPTER 3. EXPLODED VIEWS AND PARTS LIST
NOTE:
� Items marked � * � are not stocked since they are seldom required for routine service. Some delay should be anticipated when ordering these items. � The mechanical parts with no reference number in the exploded views are not supplied. � When two or more parts are shown in parallel, use the part described first as the main part. � The parts marked � $ � are the High Value Modules. � The parts marked � # � are the parts on which barcode label is attached. For the barcode label, refer to CHAPTER 4.
The components identified by mark 0 or dotted line with mark 0 are critical for safety. Replace only with part number specified. Les composants identifiés par une marque 0 sont critiques pour la sécurité. Ne les remplacer que par une pièce portant le numéro spécifié.
Confidential
3-1 PCGA-DSM51 (J/AM/EU)
|
|
|
> |
|
