The service was quick and simple, finding the service manual easy and it appears to be the original with colour schematics. It contained the info I was after and so sorted the problem.
I have copied it to CD and attached the envelope to the inside back cover of the owners manual. Good manual and excelent service. Robin Wood, Wood Electronics, New Zealand.
;
Exactly what was needed to assess the product - excellent value and great service
;
Nice to have the service manual for the Sony DCR-TRV345E now. The document is of excellent quality.
;
MACKIE HR824 26 pages English-only Service Manual contains:
1) HR824 technical overview with the description of front and rear panel switches.
2) HR824 specs
3) Block Diagram
4) Wiring Diagram
5) Packaging management
6) Spare part & final assembly list (for PCB rev A and B) + exploded view
7) Test Procedures (where, how to measure voltage...) including Test Point diagram on the PCB.
8) IC and Transistor charts.
Excellent guide: very clear, good scan quality enabling us to print readable diagram :-)
Note:
Mackie HR824 make extensive use of surface mount devices (SMD). Service on the HR824 must
only be undertaken by experienced service technicians with the right tools, experience and patience to perform surface mount rework when needed.
;
This Service manual is very well scanned and its clean to read, no any anti-theft words that un-english could understand. I got my CCD600 working with this manual and it´s clear shematics :)
1-4.Replacing the CPU
1. Removing the CPU
1
2
1 Insert a screwdriver tip into the groove as shown and slant it in the direction of the arrow. NOTE: Do not use screwdrivers having a large tip than the width of the groove. Otherwise, it may cause the groove to be damaged. The base under the CPU moves slightly in the direction of the arrow and the lock is released.
2 The CPU can be removed upward.
2. Installing the CPU
Attach the CPU while aligning the cut-out with this position.
2
1
1 Insert all pins of the replacement CPU into the holes of the base and push the CPU in the direction of the arrow.
2 Insert a screwdriver tip into the groove as shown and slant it in the direction of the arrow. The base under the CPU moves slightly in the direction of the arrow and the CPU is locked.
Confidential
PCG-FX210 (UC) 1-10
|
|
|
> |
|
