3-4. Connector Section (CH Type only)
Ref.No. 901
Fig.
Part No.
Description
1-817-023-11 [CH]...CONNECTOR, USB
USB connector
902
1-779-745-21 [CH]...JACK, DC
DC IN connector
903
901
X-4625-501-1 [CH]...BRACKET IO ASSY
I/O Bracket
� Among the parts that are used on the boards of this model, only the connectors that are show in the list can be replaced. (The parts other that the specified connectors cannot be replaced.)
902
903
902
901
902
901
Confidential
3-9 3-10 (END) PCG-GRS750 (AM)
|
|
|
> |
|
