Mounting standard metal fixtures (PDA-4001 � PDA-4002)
4.10.4 White balance
When the infrared reduction filter (PDA-4001) is mounted on the display, the tone may change. In this case, we recommend that you adjust the white balance.
4.10.5 Mounting the PDP bracket (PDK-4005) with PDA-4001 and PDA-4002 mounted
To attach the PDP bracket (PDK-4005) with the PDA-4001 and PDA-4002 mounted, tighten along with the filter-supporting metal fixture, as shown below.
M8 wave washers (supplied with the PDK-4005)
Hexagonal socket head button bolt (M8 x M18) (supplied with the PDA4001 and 4002) Hexagonal socket head button bolt (M8 x M18) (supplied with the PDA4001 and 4002)
Hexagonal socket head button bolt (M8 x M18) (supplied with the PDA4001 and 4002)
Hexagonal socket head button bolt (M8 x M18) (supplied with the PDA4001 and 4002)
In this case, use both the hexagonal socket-head button bolt (M8 x 18) and the washer supplied with the PDA-4001 or PDA-4002. If the PDK-4005 is tightened using the hexagonal socket-head button bolt (M8 x Caution 14) supplied with the PDK-4005, the screw is too short to provide sufficient strength. To ensure safe operation, use the M8 x 18 bolt.
95 <Ver. 2.1>
|
|
|
> |
|
