1. EXPLODED VIEWS AND PARTS LIST
NOTES:
A
Parts marked by "NSP" are generally unavailable because they are not in our Master Spare Parts List. The mark found on some component parts indicates the importance of the safety factor of the part. Therefore, when replacing, be sure to use parts of identical designation.
1.1 PACKING
4 6: ��
B
4 2 3 4 1 4 4
C
4 5
D
� PACKING Parts List
Mark No.
1 2 3 4 5 NSP
NSP
Description
Part No.
E
NSP
Operating Instructions AZR1176 (Japanese/English/French/Spanish German/Italian/Dutch/Trad-Chinese) Base Cover AZN2678 Stand Pipe AZN2691 Packing Set AZH1176 Screw Set AZE1142 Hexagonal Wrench AZE1129 Screws (4x8) ����� Installation Bolt(M8x20) ����� Installation Bolt(M8x40) ����� Light-Blocking Shield AZN2679
6
F
2
1 2
PDK-TS23
3 4
|
|
|
> |
|
