Transition of the Ofs voltage during adjustment of VOL OFFSET_min
A
Example: Initial value of the set Ofs: 33 V Tentative set value of Ofs (Ofs set value for the panel inspection): 35 V VOL OFFSET_min1 (pale purpel): 19 V VOL OFFSET_min2 (light blue): 17 V VOL OFFSET_min3 (violet): 15 V
Ofs voltage (V) White A luminescent spot appears. Measure the lower limit of the Ofs voltage. 36 34 32 30 28 26 24 22 20 18 16 14 12 Ofs15V A luminescent spot appears. Measure the lower limit of the Ofs voltage. A luminescent spot does not appear. The lower limit of the Ofs voltage is 15 V.
B
Full white
Ofs15V
C
Pale purple
A luminescent spot disappears.
VOL OFFSET_min1
VOL OFFSET_min2
A luminescent spot disappears.
VOL OFFSET_min3
D
� The transition process for VOL OFFSET_max is the same as the above.
Ofs15V
Completed
Light blue
Full white
Violet
E
F
PDP-5000EX
5 6 7 8
113
|
|
|
> |
|
