FOR PRECAUTION OF REASSEMBLY AND DISASSEMBLY
A
The grille is attached to the baffle using double-sided self-adhesive tape. To avoid damaging the cabinet, work with the speaker on top of a blanket or similar, face the grille upward. There is slot in the lower part of the speaker. Insert a screwdriver(-) into slot and push up detach the lower part. Taking care not to damage the grille and baffle, lift the grille a little bit at a time with hand. When reattaching the grille, use double-sided self-adhesive tape in the locations shown in the diagram and press the grille assy into place. The grille is fixed using boss and double-sided self-adhesive tape(The tape is in the locations indicated in the diagram below). Do not use a dryer to heat the self-adhesive tape when removing the grille. The woofer is attached to the baffle by 4 internal screws. To detach it, first remove the baffle from cabinet. Then unfasten those screws. When attaching it, face its plus terminal downward. The tweeter is attached to the baffle by 2 internal screws. To detach it, first remove the baffle from cabinet. Then unfasten those screws. When attaching it, face its plus terminal rightward.
LOCATIONS TO FIX DOUBLE-SIDED SELF-ADHESIVE TAPE
Tape (SEH1080 x 2)
B
C
GRILLE
Slot
D
Grille ASSY (Back Side)
Screwdriver(-) Grille
E
Baffle
F
2
1 2
PDP-S35
3 4
|
|
|
> |
|
