s Prism P.B.S. adjustment
Screws-B
Slot-A
[Adjustment] 1. Input a 100% of white raster signal. 2. Loosen 2 screws B. 3. Insert a slot screwdriver into slot A and adjust the maximum brightness on center position of screen. 4. Tighten the 2 screws B to fix the prism PBS.
/1672
s Polarized-glass adjustment
Slot-B
R, G or B polarized glass adjustment
1. Input a 100% of black raster signal. 2. Loosen 2 screws A on the polarized glass which you intend to adjust. (R, G or B) 3. Insert a slot screwdriver into slot B and adjust the lowest level in black on screen. 4. Tighten the 2 screws A to fix the polarized glass.
Screws-A
/1675
-41-
|
|
|
> |
|
